Lenovo ThinkSystem SR650 V4 24-Bay SFF 2U Rack Server Chassis

The Lenovo ThinkSystem SR650 V4 is the latest generation 2-socket 2U rack server built on Intel Xeon 6 processors with P-cores, offering up to 86 cores and 350W TDP per socket. It maximizes scalability with up to 8TB DDR5 at 8000MHz using MRDIMMs, 10 PCIe 5.0 expansion slots, and extensive storage including front, mid, and rear drive bays supporting SFF, LFF, and E3.S NVMe configurations. Designed for AI, analytics, and mission-critical enterprise applications.

Specifications

• CPU Sockets: 2
• Processor Support: Intel Xeon 6 (6700/6500-series P-cores, up to 86 cores, 350W TDP)
• Memory Slots: 32
• Memory Type: DDR5 TruDDR5 up to 6400MHz (RDIMMs) or 8000MHz (MRDIMMs)
• Max Memory: 8192 GB
• Drive Bays: Front: up to 24x 2.5-inch or 32x E3.S or 12x 3.5-inch; Mid: up to 8x 2.5-inch; Rear: up to 8x 2.5-inch or 4x 3.5-inch
• PCIe Slots: Up to 10x PCIe 5.0 slots + 1x OCP 3.0 SFF slot
• Power Supply: 2x hot-swap (up to 2400W)
• Form Factor: 2U Rack
• Generation: V4 (Intel Xeon 6)
• Dimensions: 482.0 x 868.4 x 86.5 mm (WxDxH)
• Weight: 33.0 kg
