PN: DL320-G12-20EDSFF-1U

HPE ProLiant Compute DL320 Gen12 20-Bay EDSFF 1U Rack Server

ICD Verified — Tested & Warranted
Price Match Promise — Found it cheaper? We'll match it.

Price on request

HPE Server System — Part #DL320-G12-20EDSFF-1U
Compatible with HPE ProLiant servers. Tested & quality guaranteed.

The HPE ProLiant Compute DL320 Gen12 is a single-socket 1U rack server powered by Intel Xeon 6 processors with up to 144 cores. It doubles memory capacity to 4TB DDR5-6400 across 16 DIMM slots. Supporting up to 20 EDSFF drives, 12 LFF, or 4 LFF configurations with front or rear-facing GPU support for up to 4 single-wide GPUs, it delivers exceptional single-socket density for modern edge and datacenter workloads.

Specifications

  • CPU Sockets: 1
  • Processor Support: Intel Xeon 6 (up to 144 cores)
  • Memory Slots: 16
  • Memory Type: DDR5-6400
  • Max Memory: 4096 GB
  • Drive Bays: Up to 20x EDSFF or 12x LFF or 4x LFF
  • PCIe Slots: 2x PCIe 5.0 x16, front/rear OCP
  • Power Supply: 2x 800W/1600W redundant
  • Form Factor: 1U Rack
  • Generation: Gen12 (2025)
  • Dimensions: 4.29 x 43.46 x 69.97 cm (1.69 x 17.11 x 27.55 in)
  • Weight: 14.5 kg
