Best Parts for Huawei FusionServer
Complete compatibility guide for the Huawei FusionServer. The parts listed are the component families ICD lists for the Huawei FusionServer; part-level fit is confirmed on every quote.
The Huawei FusionServer has Varies CPU sockets and up to Varies memory. ICD Group lists 210 compatible parts for it in 11 component categories, led by Networking (69), Memory (27) and SSD (26), with 46 distinct configurations. The parts listed are the component families ICD lists for the Huawei FusionServer; part-level fit is confirmed on every quote.
Server Specifications
| Brand | Huawei |
| Model | Huawei FusionServer |
| Type | Server |
| CPU Sockets | Varies |
| Maximum Memory | Varies |
| Lifecycle Status | End of sale |
| Processor Options | FusionServer Pro rack family; 2288H V5: 2U, dual Intel Xeon Scalable (Cascade Lake) |
| Memory Configuration | 24x DDR4 DIMM slots (2288H V5) |
| Drive Configurations | 2288H V5: up to 28x NVMe SSD, or 20x 3.5in, or 31x 2.5in drives |
| Networking Options | 10x PCIe slots; DEMT energy management, FDM fault diagnosis |
| Specification Source | Huawei official documentation (verified 2026-07-02) |
Frequently Asked Questions
Memory for Huawei FusionServer
15 memory configurations listed for the Huawei FusionServer, 27 parts in total. Each row is one configuration ICD supplies; the part numbers are examples from that row.
| Capacity | Speed | Type | Parts | Example part numbers |
|---|---|---|---|---|
| 32 GB | — | RDIMM ECC Registered | 5 | 06200214, 06200241, 06200266 |
| 16 GB | — | RDIMM ECC Registered | 3 | 06200213, 06200240, 06200317 |
| 64 GB | — | RDIMM ECC Registered | 3 | 06200282, 06200319, 06200351 |
| 128 GB | — | RDIMM ECC Registered | 2 | 06200288, 06200352 |
| 32 GB | — | RDIMM | 2 | N24DDR403, N26DDR402 |
| 32 GB | 2400 MHz | RDIMM ECC Registered | 2 | 06200224, N24DDR405 |
| 64 GB | 2666 MHz | RDIMM ECC Registered | 2 | 06200242, N26DDR464 |
| 128 GB | 2400 MHz | ECC | 1 | 06200235 |
| 16 GB | 1600 MHz | RDIMM | 1 | 06200121 |
| 16 GB | 2133 MHz | RDIMM ECC Registered | 1 | 06200176 |
| 32 GB | 2666 MHz | RDIMM ECC Registered | 1 | 06200260 |
| 32 GB | 2933 MHz | RDIMM ECC Registered | 1 | 06200303 |
| 64 GB | — | RDIMM | 1 | N29DDR404 |
| 64 GB | 2400 MHz | LRDIMM ECC | 1 | N24DDR407 |
| 64 GB | 2933 MHz | RDIMM ECC Registered | 1 | N29DR4G4B64 |
SSD for Huawei FusionServer
21 ssd configurations listed for the Huawei FusionServer, 26 parts in total. Each row is one configuration ICD supplies; the part numbers are examples from that row.
| Capacity | Interface | Form Factor | Speed | Parts | Example part numbers |
|---|---|---|---|---|---|
| — | NVMe | — | Solid State (no rotational speed) | 3 | ES3000 V5, ES3600C V5, ES3600C V6 |
| 1.92 TB | SAS | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 2 | 02312GQV, 02312GUE |
| 3.84 TB | SAS | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 2 | 02312GQW, 02312GUF |
| 960 GB | SAS | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 2 | 02312FRC, 02312GQU |
| 1.6 TB | NVMe | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312NAK |
| 1.92 TB | NVMe | — | Solid State (no rotational speed) | 1 | 02312HKD |
| 1.92 TB | SATA | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312TEN |
| 15.36 TB | NVMe | — | Solid State (no rotational speed) | 1 | 02312HKG |
| 240 GB | SATA | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312GQS |
| 240 GB | SATA | M.2 | Solid State (no rotational speed) | 1 | 02312NME |
| 3.2 TB | NVMe | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312NAL |
| 3.84 TB | NVMe | — | Solid State (no rotational speed) | 1 | 02312HKE |
| 3.84 TB | SATA | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312TKR |
| 32 GB | SATA | M.2 | Solid State (no rotational speed) | 1 | 02312BLQ |
| 480 GB | SATA | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312GQT |
| 6.4 TB | NVMe | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312NAM |
| 64 GB | SATA | M.2 | Solid State (no rotational speed) | 1 | 02312KGR |
| 7.68 TB | NVMe | — | Solid State (no rotational speed) | 1 | 02312HKF |
| 800 GB | NVMe | — | Solid State (no rotational speed) | 1 | 02312HJX |
| 960 GB | NVMe | — | Solid State (no rotational speed) | 1 | 02312HKH |
| 960 GB | SATA | 2.5" Small Form Factor (SFF) | Solid State (no rotational speed) | 1 | 02312DCT |
RAID / HBA for Huawei FusionServer
3 raid / hba configurations listed for the Huawei FusionServer, 17 parts in total. Each row is one configuration ICD supplies; the part numbers are examples from that row.
| Controller | Interface | Speed | Parts | Example part numbers |
|---|---|---|---|---|
| RAID Controller | — | — | 12 | 02311QWC, 02311YMJ, 02312BEC |
| RAID Controller | SAS / SATA | — | 3 | 02310UUB, BC11RLCA, BC1M05ESMQ |
| RAID Controller | SAS | — | 2 | BC1RLCA01, BC61ESMLB |
Hard Drive for Huawei FusionServer
7 hard drive configurations listed for the Huawei FusionServer, 10 parts in total. Each row is one configuration ICD supplies; the part numbers are examples from that row.
| Capacity | Interface | Form Factor | Speed | Parts | Example part numbers |
|---|---|---|---|---|---|
| 600 GB | SAS | 2.5" Small Form Factor (SFF) | 10,000 RPM (10K) | 4 | 02311HAP, 02311HAT, 02312RBW |
| 1.2 TB | SAS | 2.5" Small Form Factor (SFF) | 10,000 RPM (10K) | 1 | 02311PGT |
| 1.8 TB | SAS | 2.5" Small Form Factor (SFF) | 10,000 RPM (10K) | 1 | 02311SHG |
| 2.4 TB | SAS | 2.5" Small Form Factor (SFF) | 10,000 RPM (10K) | 1 | 02312GHN |
| 300 GB | SAS | 2.5" Small Form Factor (SFF) | 15,000 RPM (15K) | 1 | 02311PGR |
| 4 TB | SAS | 3.5" Large Form Factor (LFF) | 7,200 RPM (7.2K) | 1 | 02311AYV |
| 8 TB | SATA | 3.5" Large Form Factor (LFF) | 7,200 RPM (7.2K) | 1 | 02311EAP |
Post-Warranty Support for Huawei FusionServer
ICD Care+ TPM covers the Huawei FusionServer past OEM end-of-support: parts and on-site support at SLA levels set per contract, typically 40-60% less than OEM post-warranty support.
Learn About ICD Care+ →Frequently Asked Questions — Huawei FusionServer
What memory is compatible with the Huawei FusionServer?
The memory modules listed are the component families ICD lists for the Huawei FusionServer; part-level fit is confirmed on every quote. Maximum capacity: Varies. Module type, speed and rank are confirmed against your configuration on the quote.
Does ICD ship Huawei FusionServer parts to Egypt, UAE, KSA?
Yes. Egypt: same-day in Cairo Metro or 1-2 days. North Africa: 2-4 days. GCC (Saudi Arabia, UAE, Kuwait, Qatar, Bahrain, Oman) and Levant: 3-4 days. East Africa: 4-6 days. West Africa: 5-7 days. Southern Africa: 5-8 days. Europe: 3-5 days. North America: 5-7 days. Asia: 4-7 days. Express door-to-door from Cairo via DHL, Aramex or FedEx; customs clearance may add 1-3 days. Exact transit time is stated per quote. For NTRA-regulated networking parts bound for Egypt, the import route is stated per quote.
Is the Huawei FusionServer still supported?
No OEM end-of-support date is on record for the Huawei FusionServer. ICD Care+ TPM continues hardware support and parts at SLA levels set per contract.
How do I get a compatibility-verified quote?
Send your part list or workload requirement via the quote form or WhatsApp +20 104 022 22 14. We reply within 24 hours with a USD quotation matched by part number; the lead time is stated on each quote.
Are ICD parts for the Huawei FusionServer new or refurbished?
Both, clearly labeled on every listing and quote: New, Renewed or Refurbished (tested). Every ICD part except consumables carries a warranty: 1 year included on drives, power supplies and other wear parts, 3 years included on CPUs, memory, networking and optics, and extendable up to 10 years.
Compatible Components
Networking
Memory
SSD
RAID / HBA
Power & Cooling
Storage
Riser
Processors
Hard Drive
System Boards
Wireless
Related Resources
Need a custom configuration?
Our team can build a complete parts list for your Huawei FusionServer, with compatibility confirmed on the quote.
Get a Custom Quote
